LED 6” High Abuse Shallow Plenum Luminaire

VRRV6

VRRV6 is a high-abuse, shallow plenum strip luminaire engineered for environments where durability, reliability, and long-term performance are essential. Designed specifically for high-abuse areas, this vandal-resistant fixture combines a fully luminous aperture with rugged construction to deliver consistent illumination while helping reduce maintenance and replacement costs. Its backlit design produces a smooth, uniform light distribution that enhances visual comfort, while the impact-resistant polycarbonate lens protects the fixture from damage in demanding public spaces. The VRRV6 is an ideal vandal resistant lighting solution for facilities that require both strength and a clean architectural appearance.

Built with a formed steel housing and extruded aluminum frame, the VRRV6 is designed to withstand the challenges commonly found in corridors, day rooms, locker rooms, entryways, and public transit terminals. The fixture features a seamless full-coverage protective lens that extends across the entire exposed room-side surface, creating a durable barrier against tampering and impact. The lens is permanently secured with a high-bond adhesive gasket, further enhancing protection while maintaining a sleek and unobtrusive appearance. For facilities managers and specifiers seeking dependable recessed lighting solutions, the shallow profile design offers installation flexibility in spaces where plenum depth may be limited.

Performance and versatility are at the core of the Reveal6 VRRV6. Field-selectable lumen packages and color temperatures allow lighting levels to be customized for a variety of applications without sacrificing efficiency or visual quality. High-efficiency LED modules are closely regulated to maintain consistent color performance, lumen output, and efficacy over time. Standard 80+ CRI illumination supports visibility and occupant comfort, while efficacy exceeding 100 lumens per watt in many configurations helps reduce energy consumption. The fixture is also equipped with a programmable constant-current driver that supports 0-10V dimming to 1%, giving users greater control over lighting environments while supporting energy-management goals.

Engineered for long-term reliability, the VRRV6 offers an L80 LED lifetime exceeding 60,000 hours, helping minimize maintenance demands in busy facilities. Its IK10 impact rating demonstrates exceptional resistance to physical abuse, while ETL Wet Location certification expands application possibilities in environments exposed to moisture. By combining robust construction, flexible performance options, and a visually appealing luminous surface, the Reveal6 VRRV6 provides a practical and dependable lighting solution for high-traffic spaces where durability cannot be compromised. Whether used as part of a new construction project or a retrofit application, this strip luminaire delivers the performance, protection, and appearance needed to support modern facility requirements.

  • Designed specifically for high-abuse areas with an IK10-rated impact-resistant construction.
  • Fully luminous aperture creates a smooth, uniform light distribution that improves visual comfort.
  • Field-selectable lumen outputs and CCT settings provide application flexibility.
  • Shallow plenum design supports installation where ceiling space is limited.
  • ETL Wet Location listed with LEDs rated for more than 60,000 hours of operation.
Specifications
Instruction Sheet
Country of Origin: Canada

Specifications

IES

Revit

Instruction Sheet

Resources

Technical Information

  • Product Specifications

    Application : Day Room, Entryways, Locker Room, Hallways, Public Space

    Available Size(s) : 24",48",96"

    Brand : CER

    CRI : 80+

    Certification : ETL Listed, RoHS Compliant, Wet Locations, IK10

    Color Temperature : 3050KS

    Fixture Type : Recessed, Strip, Linear, T-Bar

    Grade : Specification Grade

    Light Source : LED

    Lumen Output : 11/15/20LS, 21/29/39LS, 43/58/79LS

    Market : High-Abuse, General Area
