LED - Medical Patient Room Recessed Luminaire

MD1-4104

MD1‑4104 is a recessed LED ambient fixture purpose‑built for ICU, exam & isolation lighting, giving clinical spaces balanced illumination with a sealed, cleanable design. As a medical lighting solution, it’s engineered for hospitals, nursing homes, and other patient care facilities where durability, hygiene, and visual comfort matter. The luminaire’s single‑piece aluminum door frame with a clear acrylic lens is gasketed to support easy wipe‑downs and routine infection‑control practices, while the frosted acrylic diffuser delivers comfortable, even light.

The MD1‑4104 is built to perform day in and day out. Long‑life LEDs paired with high‑efficiency drivers achieve L80 >60,000 hours for dependable operation and reduced maintenance. Standard 0–10V dimming and THD <10% help maintain power quality and smooth control across patient room lighting scenarios from daytime rounds to nighttime comfort levels. When protective environments are required, specify the IP65 option with ISO5 cleanroom rating to support isolation rooms and sensitive areas. Housing is precision‑formed cold‑rolled steel with a high‑reflectivity matte white finish; an antimicrobial finish is also available to further support cleanliness goals.

Designed for flexible installation, MD1‑4104 offers grid (IG) and flange (IF) mount types with integral earthquake clips, plus sizes in 1×4, 2×2, and 2×4 to fit common ceiling modules and over‑bed luminaire layouts without complicating construction. Output ranges from 3,300 to 7,800 nominal lumens with typical wattages from 31 to 75, giving you the right light level for ambient tasks and comfort. Choose 3500K or 4000K with 80+ CRI to balance visual acuity and patient comfort, and add options like DALI controls, emergency battery packs, night light, or an RFI filter for sensitive equipment areas. Approvals include CSA/UL with suitability for damp locations, so you can standardize MD1‑4104 across a range of clinical zones with confidence. Altogether, these choices make MD1‑4104 a versatile piece of medical lighting that supports consistent patient room lighting while simplifying specification and maintenance. [

In short, MD1‑4104 helps facilities deliver reliable, cleanable illumination that feels good for patients and works for staff. If you’re upgrading patient room lighting or planning new clinical spaces, this fixture gives you proven performance, practical options, and easy‑to‑clean construction—ideal for ICU, exam & isolation lighting and over‑bed luminaire applications.

  • Sealed, gasketed single‑piece aluminum door frame with clear acrylic lens and frosted acrylic diffuser for easy cleaning and visual comfort.
  • Long‑life LEDs with high‑efficiency drivers: L80 >60,000 hours, 0–10V dimming, and THD <10% for smooth control and power quality.
  • Optional IP65 ingress protection with ISO5 cleanroom rating for use in protective environments and isolation rooms.
  • Sizes and mounts to fit common ceiling grids: 1x4, 2x2, 2x4; IG (grid) and IF (flange) mounting with integral earthquake clips.
  • Configurable performance and approvals: 3,300–7,800 lumens, 31–75W, 3500K/4000K, 80+ CRI; CSA/UL listed and suitable for damp locations.
Country of Origin: Canada

Product Information

  • Product Specifications

    Application : Chronic Care Facilities,Healthcare,Hospitals,Nursing Homes

    Available Size(s) : 2x2,2x4

    Brand : CER

    CRI : 80 - 89

    Certification : Built to CSA & UL Standards,UL Listed (C/US)

    Color Temperature : 3500K,4000K

    Fixture Type : General Area,Medical,Recessed,Surface

    Grade : Specification Grade

    Light Source : LED

    Lumen Output : 3001-4000,5001-10000

    Market : Damp/Wet Location,Healthcare
